| Artikelnummer | NL128102BC29-01C |
| Marke | NLT |
| Größe | 19.0 |
| Anwendung | DMPC |
| Auflösung | 1280×1024 |
| Komposition | LCM |
| Helligkeit | 270 |
| CR | 450:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | NEC |
| Panel-Modell | NL128102BC29-01C |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 19.0 inch |
| Auflösung | 1280(RGB)×1024 , SXGA |
| Anzeigemodus | SA-SFT, Normally Black, Transmissive |
| aktiver Bereich | 376.32×301.056 mm |
| Umriss | 404.2×330×25.55 mm |
| Oberfläche | Antiglare, Hard coating (2H) |
| Helligkeit | 270 cd/m² (Typ.) |
| Kontrastverhältnis | 450:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 10/10 (Typ.)(Tr/Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | DMPC |
