| Artikelnummer | CLAA101WJ03 XG |
| Marke | CPT |
| Größe | 10.1 |
| Anwendung | PAD |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 600:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | CPT |
| Panel-Modell | CLAA101WJ03 XG |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.1 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | HFFS, Normally Black, Transmissive |
| aktiver Bereich | 223.341×125.568 mm |
| Umriss | 234.93×139.17×4.3 mm |
| Oberfläche | Hard coating |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Min.) |
| Farben anzeigen | 16.7M (8-bit), CIE193150% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S6PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 39 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
