| Artikelnummer | A025DN01 V9 |
| Marke | AUO |
| Größe | 2.5 |
| Anwendung | DSC |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Serial RGB |
| Panel-Marke | AUO |
| Panel-Modell | A025DN01 V9 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 2.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 49.92×37.44 mm |
| Umriss | 59.63×43.7×2.9 mm |
| Oberfläche | Hard coating |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 15/20 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsWLED |
| Signalschnittstelle | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| Eingangsspannung | 3.3/15/-10V (VDD/VGH/VGL) |
| Anwendung | DSC |
| A025DL02 V5 | AUO | 2.5 | 320×240 |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| A025DN01 V9 | AUO | 2.5 | 320×240 |
| ACX385AKM-7 | SONY | 2.5 | 640×240 |
| H245QBN02.0 | AUO | 2.5 | 240×432 |
| LMS246GF06 | Samsung | 2.5 | 320×240 |
| LQ025Q3DW01 | SHARP | 2.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| TD025THEA3 | TPO | 2.5 | 320×240 |
| A015AN03 | AUO | 1.46 | 280×220 |
| A027DN03 V3 | AUO | 2.7 | 320×240 |
| A027DTN01.2 | AUO | 2.7 | 320×240 |
| A030DN05 V0 | AUO | 3.0 | 320×240 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| TD025THEG1 | TPO | 2.5 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
