| Artikelnummer | TFT2N0369-E |
| Marke | Other |
| Größe | 3.2 |
| Anwendung | MPH |
| Auflösung | 240×320 |
| Komposition | LCM |
| Helligkeit | 185 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | CPU/RGB/SPI |
| Panel-Marke | TRULY |
| Panel-Modell | TFT2N0369-E |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 3.2 inch |
| Auflösung | 240(RGB)×320 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 48.6×64.8 mm |
| Umriss | 57.54×79.2 mm |
| Oberfläche | |
| Helligkeit | 185 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 29.5 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/64/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S1PWLEDWithout Driver |
| Signalschnittstelle | CPU/RGB/SPI, 40 pins |
| Eingangsspannung | 3.0V (Typ.) |
| Anwendung | MPH |
| 32WQF0H | SII | 3.2 | 240×400 |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| RGS32256064WH002 | RiTdisplay | 3.2 | 256×64 |
| TFT1N6248-E | Other | 3.2 | 240×320 |
| TFT2N0369-E | Other | 3.2 | 240×320 |
| TM032PDZ04 | Tianma | 3.2 | 320×480 |
| TM032PDZ13 | Tianma | 3.2 | 320×480 |
| TM032PDZ16B | Tianma | 3.2 | 320×480 |
| AMS397GE66 | Samsung | 4.0 | 480×800 |
| AMS410GC01-0 | Samsung | 4.1 | 480×800 |
| H335VVN01.0 | AUO | 3.4 | 480×854 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| HVA37WV1-ME0 | HYDIS | 3.7 | 480×800 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS063R1SX01 | SHARP | 6.3 | 1440×2560 |
| TD025THED2 | TPO | 2.5 | 320×240 |
| TM020HBH03 | Tianma | 2.0 | 240×320 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
