| Artikelnummer | SP10Q010 |
| Marke | KOE |
| Größe | 3.8 |
| Anwendung | IA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 110 |
| CR | 20:1 |
| Farben | Monochrome |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | Parallel Data |
| Panel-Marke | KOE |
| Panel-Modell | SP10Q010 |
| Plattentyp | FSTN-LCD , LCM |
| Panelgröße | 3.8 inch |
| Auflösung | 320×240 , QVGA |
| Anzeigemodus | STN, Black/White (Negative), Transmissive |
| aktiver Bereich | 76.79×57.59 mm |
| Umriss | 94.7×73.3×6 mm |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 110 cd/m² (Typ.) |
| Kontrastverhältnis | 20:1 (Typ.) |
| Farben anzeigen | Monochrome |
| Reaktionszeit | 150/350 (Typ.)(Tr/Td) |
| Blickwinkel | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| Frequenz | 75Hz |
| Lampentyp | 1S6PWLEDWithout Driver |
| Signalschnittstelle | Parallel Data (4-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
