| Artikelnummer | NL3224AC35-10 |
| Marke | NLT |
| Größe | 5.5 |
| Anwendung | IA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 85:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | NEC |
| Panel-Modell | NL3224AC35-10 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 111.36×83.52 mm |
| Umriss | 134×110 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (2H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 85:1 (Typ.) |
| Farben anzeigen | Full color , CIE193150% |
| Reaktionszeit | 16/44 (Typ.)(Tr/Td) |
| Blickwinkel | 50/50/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLEmbedded (Inverter) |
| Signalschnittstelle | Analog RGB, 24 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | IA |
