| Artikelnummer | PD080SY1 |
| Marke | E Ink |
| Größe | 8.0 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 300 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | PVI |
| Panel-Modell | PD080SY1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 8.0 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 162×121.5 mm |
| Umriss | 174.4×133.1×6.74 mm |
| Oberfläche | Antiglare |
| Helligkeit | 300 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 3S10PWLEDWithout Driver |
| Signalschnittstelle | TTL (1 ch, 6-bit), 50 pins |
| Eingangsspannung | 3.3/3.3/9.6/18/-6V (Typ.)(VCC1/VCC2/AVDD/VDDG/VEEG) |
| Anwendung | IA |
