| Artikelnummer | N150P2-L06 |
| Marke | IDTech |
| Größe | 15.0 |
| Anwendung | NBPC |
| Auflösung | 1400×1050 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 250:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | IDTech |
| Panel-Modell | N150P2-L06 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.0 inch |
| Auflösung | 1400(RGB)×1050 , SXGA+ |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 304.5×228.375 mm |
| Umriss | 317.3×242×6.5 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Antiglare |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 45/45 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
