| Artikelnummer | LC150X01-SL01 |
| Marke | LG Display |
| Größe | 15.0 |
| Anwendung | LCTV |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 430 |
| CR | 450:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LC150X01-SL01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.0 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | S-IPS, Normally Black, Transmissive |
| aktiver Bereich | 304.128×228.096 mm |
| Umriss | 332.8×262.8×22.7 mm |
| Oberfläche | Antiglare (Haze 25%), Hard coating (3H) |
| Helligkeit | 430 cd/m² (Typ.) |
| Kontrastverhältnis | 450:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 12/13 (Typ.)(Tr/Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 20 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
