| Artikelnummer | LTN097XL02-A01 |
| Marke | Samsung |
| Größe | 9.7 |
| Anwendung | PAD |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 440 |
| CR | 900:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTN097XL02-A01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 9.7 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | PLS, Normally Black, Transmissive |
| aktiver Bereich | 196.608×147.456 mm |
| Umriss | 210.33×164.37×5.12 mm |
| Oberfläche | Hard coating (2H) |
| Helligkeit | 440 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193150% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6 stringsWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
