| Artikelnummer | LQ104V1DG51 |
| Marke | SHARP |
| Größe | 10.4 |
| Anwendung | IA |
| Auflösung | 640×480 |
| Komposition | LCM |
| Helligkeit | 350 |
| CR | 300:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LQ104V1DG51 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.4 inch |
| Auflösung | 640(RGB)×480 , VGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 211.2×158.4 mm |
| Umriss | 246.5×179.4×15.5 mm |
| Oberfläche | Antiglare, Hard coating (3H), Antireflection |
| Helligkeit | 350 cd/m² (Typ.) |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 20/40 (Typ.)(Tr/Td) |
| Blickwinkel | 70/70/40/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 31 pins |
| Eingangsspannung | 3.3/5.0V (Typ.) |
| Anwendung | IA |
| LQ104S1LG31 | SHARP | 10.4 | 800×600 |
| LQ104S1LG32 | SHARP | 10.4 | 800×600 |
| LQ104V1DC31 | SHARP | 10.4 | 640×480 |
| LQ104V1DG11 | SHARP | 10.4 | 640×480 |
| LQ104V1DG33 | SHARP | 10.4 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| LQ104V1DG5B | SHARP | 10.4 | 640×480 |
| LQ104V1DG72 | SHARP | 10.4 | 640×480 |
| LQ104V1DG83 | SHARP | 10.4 | 640×480 |
| LQ104V1DW01 | SHARP | 10.4 | 640×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA121XK04 | Mitsubishi | 12.1 | 1024×768 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| G240HW01 V0 | AUO | 24.0 | 1920×1080 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| LQ150X1LW71N | SHARP | 15.0 | 1024×768 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP10Q010 | KOE | 3.8 | 320×240 |
