| Artikelnummer | LP101WX1-SLB1 |
| Marke | LG Display |
| Größe | 10.1 |
| Anwendung | PAD |
| Auflösung | 1280×800 |
| Komposition | Assembly |
| Helligkeit | 340 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP101WX1-SLB1 |
| Plattentyp | a-Si TFT-LCD , Assembly |
| Panelgröße | 10.1 inch |
| Auflösung | 1280(RGB)×800 , WXGA |
| aktiver Bereich | 216.96×135.6 mm |
| Umriss | 262.7×178.7×7.1 mm |
| Oberfläche | Anti Fingerprint |
| Helligkeit | 340 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Min.) |
| Farben anzeigen | 262K (6-bit) |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
