| Artikelnummer | LP101WH4-SLAA |
| Marke | LG Display |
| Größe | 10.1 |
| Anwendung | PAD |
| Auflösung | 1366×768 |
| Komposition | Assembly |
| Helligkeit | 315 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP101WH4-SLAA |
| Plattentyp | a-Si TFT-LCD , Assembly |
| Panelgröße | 10.1 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| aktiver Bereich | 222.52×125.11 mm |
| Umriss | 254.3×158×5.45 mm |
| Oberfläche | Anti Fingerprint, Hard coating (8H) |
| Helligkeit | 315 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 39 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
