| Artikelnummer | LD070WX3-SL01 |
| Marke | LG Display |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 800×1280 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | LG Display |
| Panel-Modell | LD070WX3-SL01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 800(RGB)×1280 , WXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 94.2×150.72 mm |
| Umriss | 104.32×161.67×3.84 mm |
| Oberfläche | Hard coating |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Reaktionszeit | 35 (Max.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5 stringsWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 34 pins |
| Eingangsspannung | 3.3/1.8V (Typ.)(VDD/VCC) |
| Anwendung | PAD |
