| Artikelnummer | LD070WS2-SL04 |
| Marke | LG Display |
| Größe | 7.0 |
| Anwendung | UMPC |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 600 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LD070WS2-SL04 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 153.6×90 mm |
| Umriss | 162.6×102.7×4.5 mm |
| Oberfläche | Antireflection |
| Helligkeit | 600 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC) |
| Reaktionszeit | 40 (Max.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 7S3PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | UMPC |
