| Artikelnummer | N070ICG-LD3 |
| Marke | Innolux |
| Größe | 7.0 |
| Anwendung | UMPC |
| Auflösung | 1280×800 |
| Komposition | LCM |
| Helligkeit | |
| CR | 800:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | CHIMEI INNOLUX |
| Panel-Modell | N070ICG-LD3 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1280(RGB)×800 , WXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 149.76×93.6 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 13/12 (Typ.)(Tr/Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLED |
| Signalschnittstelle | LVDS (1 ch, 6-bit) |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | UMPC |
