| Artikelnummer | LD050WV1-SP01 |
| Marke | LG Display |
| Größe | 5.0 |
| Anwendung | UMPC |
| Auflösung | 480×800 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 700:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | LG Display |
| Panel-Modell | LD050WV1-SP01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 480(RGB)×800 , WVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 64.8×108 mm |
| Umriss | 71.4×120.4×4.31 mm |
| Oberfläche | Antiglare |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S2PWLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| Eingangsspannung | 2.9V (Typ.) |
| Anwendung | UMPC |
