| Artikelnummer | LD050WQ1-TD02 |
| Marke | LG Display |
| Größe | 5.0 |
| Anwendung | DPF |
| Auflösung | 480×272 |
| Komposition | LCM |
| Helligkeit | |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | |
| Panel-Marke | LG Display |
| Panel-Modell | LD050WQ1-TD02 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 5.0 inch |
| Auflösung | 480×272(RGB) , WQVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 110.88×62.832 mm |
| Oberfläche | |
| Helligkeit | |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Dithering), CIE193148% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/65/55 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | WLED |
| Anwendung | DPF |
