| Artikelnummer | DLC1010AZG-1 |
| Marke | Other |
| Größe | 10.1 |
| Anwendung | CNS |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 1000 |
| CR | 250:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | DLC |
| Panel-Modell | DLC1010AZG-1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.1 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 222.72×125.28 mm |
| Umriss | 235×149.52 mm |
| Oberfläche | |
| Helligkeit | 1000 cd/m² (Typ.) |
| Kontrastverhältnis | 250:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | |
| Blickwinkel | 85/85/85/60 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 3S16PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 3.3/10.5V (Typ.)(VCC/AVDD) |
| Anwendung | CNS |
