| Artikelnummer | B116XAN03.1 HW0A |
| Marke | AUO |
| Größe | 11.6 |
| Anwendung | PAD |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 800:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | B116XAN03.1 HW0A |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 11.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 256.125×144 mm |
| Umriss | 270.37×159.79×4.9 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193152% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 10S3PWLEDEmbedded (LED Driver) |
| Signalschnittstelle | MIPI (4 data lanes), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
