| Artikelnummer | A070PAN01.0 |
| Marke | AUO |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 900×1440 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 900:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | A070PAN01.0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 900(RGB)×1440 , WXGA+ |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 94.23×150.77 mm |
| Umriss | 104.53×163.64×2.3 mm |
| Oberfläche | Hard coating |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 900:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193150% |
| Reaktionszeit | 18/12 (Typ.)(Tr/Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 5S4PWLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
