| Artikelnummer | V26L8060BA |
| Marke | E Ink |
| Größe | 10.4 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 550 |
| CR | 180:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | PVI |
| Panel-Modell | V26L8060BA 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.4 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 211.2×158.4 mm |
| Umriss | 243×185.1 mm |
| Oberfläche | Antiglare, Hard coating |
| Helligkeit | 550 cd/m² (Typ.) |
| Kontrastverhältnis | 180:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 15/25 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/15/40 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 14 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
