| Artikelnummer | TX26D202VM0BAA |
| Marke | KOE |
| Größe | 10.1 |
| Anwendung | IA |
| Auflösung | 1920×1200 |
| Komposition | LCM |
| Helligkeit | 800 |
| CR | 800:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | KOE |
| Panel-Modell | TX26D202VM0BAA |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 10.1 inch |
| Auflösung | 1920(RGB)×1200 , WUXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 217.44×135.9 mm |
| Umriss | 232.1×153.2×7.62 mm |
| Oberfläche | |
| Helligkeit | 800 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193155% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 50 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| B101AW06 V4 | AUO | 10.1 | 1024×600 |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| LQ101R1SX01A | SHARP | 10.1 | 2560×1600 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| TX26D202VM0BAA | KOE | 10.1 | 1920×1200 |
| TX26D203VM2BAA | KOE | 10.4 | 1024×768 |
| A150XN01 V2 | AUO | 15.0 | 1024×768 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| EL640.480-AAA | PLANAR | 10.4 | 640×480 |
| LMG7410PLFC | KOE | 5.1 | 240×128 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LTM09C016K | TOSHIBA | 9.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448BC33-71 | NLT | 10.4 | 640×480 |
| OEL9M0073-R-E | Other | 1.0 | 128×64 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
