| Artikelnummer | AA121XJ02 |
| Marke | Mitsubishi |
| Größe | 12.1 |
| Anwendung | IA |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 1000 |
| CR | 700:1 |
| Farben | 262K/16.7M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | Mitsubishi |
| Panel-Modell | AA121XJ02 1 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 245.76×184.32 mm |
| Umriss | 280×219×18.3 mm |
| Oberfläche | Hard coating (2H), Antireflection |
| Helligkeit | 1000 cd/m² (Typ.) |
| Kontrastverhältnis | 700:1 (Typ.) |
| Farben anzeigen | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| Reaktionszeit | 6/19 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/75/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| AA121SL01 | Mitsubishi | 12.1 | 800×600 |
| AA121SL03 | Mitsubishi | 12.1 | 800×600 |
| AA121SL12 | Mitsubishi | 12.1 | 800×600 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH01-DE1 | Mitsubishi | 12.1 | 1280×800 |
| AA121XH01 | Mitsubishi | 12.1 | 1024×768 |
| AA121XJ01 | Mitsubishi | 12.1 | 1024×768 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| AA121XK04 | Mitsubishi | 12.1 | 1024×768 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| EG4401S-FR-1 | Epson | 5.3 | 256×128 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| LM10V332 | SHARP | 10.4 | 640×480 |
| LM64C12P | SHARP | 9.4 | 640×480 |
| LQ060B3DW01 | SHARP | 6.0 | 768×128 |
| PM070WX9 | E Ink | 7.0 | 800×480 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
