| Artikelnummer | T576DC01 V0 |
| Marke | AUO |
| Größe | 58 |
| Anwendung | LCTV |
| Auflösung | 2560×1080 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 4000:1 |
| Farben | 1.07B |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | T576DC01 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 58 inch |
| Auflösung | 2560(RGB)×1080 , CSHD |
| Anzeigemodus | AMVA3, Normally Black, Transmissive |
| aktiver Bereich | 1349.76×569.43 mm |
| Umriss | 1410.7×628.5 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 4000:1 (Typ.) |
| Farben anzeigen | 1.07B (10-bit), CIE193172% |
| Reaktionszeit | 5.5 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (4 ch, 10-bit), 92 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
| LK580Z3LA13 | SHARP | 58 | 2560×1080 |
| T576DC01 V0 | AUO | 58 | 2560×1080 |
| V580DK1-KS2 | Innolux | 58 | 3840×2160 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-LD1 | Innolux | 58 | 3840×2160 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
| LC420DUE-SFU1 | LG Display | 42 | 1920×1080 |
| LC420DUJ-SGE3 | LG Display | 42 | 1920×1080 |
| LTY320HN03 | Samsung | 31.5 | 1920×1080 |
| T260XW03 V3 | AUO | 26.0 | 1366×768 |
| T315XW04 V3 | AUO | 31.5 | 1366×768 |
| T420HW08 V0 CELL | AUO | 42 | 1920×1080 |
| T420HW09 V1 | AUO | 42 | 1920×1080 |
| T420XW01 V9 | AUO | 42 | 1366×768 |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
| V650HP1-LS6 Rev.E | Innolux | 65 | 1920×1080 |
