| Artikelnummer | T150XG01 V0 |
| Marke | AUO |
| Größe | 15.0 |
| Anwendung | LCTV |
| Auflösung | 1024×768 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 500:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | T150XG01 V0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.0 inch |
| Auflösung | 1024(RGB)×768 , XGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 304.128×228.096 mm |
| Umriss | 326.5×253.5 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193160% |
| Reaktionszeit | 12/4 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/55 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | LCTV |
| LB150X03-TL02 | LG Display | 15.0 | 1024×768 |
| LQ150X1LGN2A | SHARP | 15.0 | 1024×768 |
| LQ150X1LW71U | SHARP | 15.0 | 1024×768 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| SVA150XG10TB | SVA-NEC | 15.0 | 1024×768 |
| T150XG01 V0 | AUO | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
| TM150XG-A02-01 | SANYO | 15.0 | 1024×768 |
| AX080E002B | KOE | 31.5 | 1366×768 |
| HV460WU2-202 | BOE | 46 | 1920×1080 |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LC420EUJ-SGE1 | LG Display | 42 | 1920×1080 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| T320HVN01.2 | AUO | 31.5 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V260B2-L01 | Innolux | 26.0 | 1366×768 |
| V420HK1-LS5 Rev.C7 | Innolux | 42 | 1920×1080 |
| V500HK1-LS6 Rev.C7 | Innolux | 50 | 1920×1080 |
