| Artikelnummer | M070SW46 R0 |
| Marke | IVO |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 1200×1920 |
| Komposition | LCM |
| Helligkeit | 380 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | MIPI |
| Panel-Marke | IVO |
| Panel-Modell | M070SW46 R0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1200(RGB)×1920 , WUXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 94.5×151.2 mm |
| Umriss | 104×161.37×3.59 mm |
| Oberfläche | Antiglare, Hard coating (3H), Antireflection |
| Helligkeit | 380 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193160% |
| Reaktionszeit | 30 (Max.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥100)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | MIPI (4 data lanes), 31 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
