| Artikelnummer | M070SWP1 R4 |
| Marke | IVO |
| Größe | 7.0 |
| Anwendung | IA |
| Auflösung | 800×480 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 500:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | IVO |
| Panel-Modell | M070SWP1 R4 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 800(RGB)×480 , WVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 153.6×86.64 mm |
| Umriss | 165×104×5.3 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193150% |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 8S2PWLEDWithout Driver |
| Signalschnittstelle | TTL (1 ch, 8-bit), 60 pins |
| Eingangsspannung | 3.3/10.4/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Anwendung | IA |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| CLAA070LH01AW | CPT | 7.0 | 800×480 |
| CLAA070NQ01 XN | CPT | 7.0 | 1024×600 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| DD070NA-02A | Innolux | 7.0 | 800×480 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LT070CB01000 | TOSHIBA | 7.0 | |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| M070SWP1 R5 | IVO | 7.0 | 800×480 |
| A150XN01 V2 | AUO | 15.0 | 1024×768 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G220SW02 V0 | AUO | 22.0 | 1680×1050 |
| LM340UW1-SSA1 | LG Display | 34 | 3440×1440 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| LQ156M3LW01 | SHARP | 15.6 | 1920×1080 |
| LTM08C351S | TOSHIBA | 8.4 | 800×600 |
| NL8060BC31-17 | NLT | 12.1 | 800×600 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
