| Artikelnummer | LTY460JN12 |
| Marke | Other |
| Größe | 46 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 550 |
| CR | 8000:1 |
| Farben | 1.06B |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | No Brand |
| Panel-Modell | LTY460JN12 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 46 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | SVA, Normally Black, Transmissive |
| aktiver Bereich | 1018.08×572.67 mm |
| Umriss | 1029.9×585.5 mm, Videowall Seam 11.7 mm |
| Oberfläche | Hard coating (2H), Reflection 1.4% (Max.) |
| Helligkeit | 550 cd/m² (Typ.) |
| Kontrastverhältnis | 8000:1 (Typ.) |
| Farben anzeigen | 1.06B (8-bit + Dithering), CIE193176% |
| Reaktionszeit | 3.5 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz (60Hz Input) |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 50 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
