| Artikelnummer | P460HVN01.1 |
| Marke | AUO |
| Größe | 46 |
| Anwendung | DID |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 500 |
| CR | 4000:1 |
| Farben | 1.07B |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | P460HVN01.1 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 46 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | AMVA3, Normally Black, Transmissive |
| aktiver Bereich | 1018.08×572.67 mm |
| Umriss | 1023.68×578.27×55.2 mm, Videowall Seam 5.6 mm |
| Oberfläche | Antiglare (Haze 11%) |
| Helligkeit | 500 cd/m² (Typ.) |
| Kontrastverhältnis | 4000:1 (Typ.) |
| Farben anzeigen | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Reaktionszeit | 6.5 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 10-bit), 51 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | DID |
| LTA460HB08 | Samsung | 46 | 1920×1080 |
| LTA460HQ16 | Samsung | 46 | 1920×1080 |
| LTY460HQ05-A01 | Samsung | 46 | 1920×1080 |
| P460HVN01.0 | AUO | 46 | 1920×1080 |
| P460HVN01.1 | AUO | 46 | 1920×1080 |
| P460HVN03.0 | AUO | 46 | 1920×1080 |
| P460HW02 V0 | AUO | 46 | 1920×1080 |
| T460HW07 V5 | AUO | 46 | 1920×1080 |
| T460HW08 V5 | AUO | 46 | 1920×1080 |
| V460H1-LS2 Rev.C7 | Innolux | 46 | 1920×1080 |
| LD470DXS-SCA1 | LG Display | 47 | 1366×768 |
| LD550DUN-TGB1 | LG Display | 55 | 1920×1080 |
| LTI216XM01 | Samsung | 21.6 | 960×960 |
| LTI460AA04 | Samsung | 46 | 1366×768 |
| LTI460HN10 | Samsung | 46 | 1920×1080 |
| LTI460HN11 | Samsung | 46 | 1920×1080 |
| LTI550HN05 | Samsung | 55 | 1920×1080 |
| LTI550HN08 | Samsung | 55 | 1920×1080 |
| LTI550HN09 | Samsung | 55 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
