| Artikelnummer | LTL070NL01-801 |
| Marke | Samsung |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 800:1 |
| Farben | 16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTL070NL01-801 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | PLS, Normally Black, Transmissive |
| aktiver Bereich | 153.6×90 mm |
| Umriss | 164.05×99.96×4.37 mm |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193150% |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 6S4PWLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 8-bit) |
| Eingangsspannung | 3.7V (Typ.) |
| Anwendung | PAD |
