| Artikelnummer | LTD056ET0S |
| Marke | TOSHIBA |
| Größe | 5.6 |
| Anwendung | UMPC |
| Auflösung | 1024×600 |
| Komposition | LCM |
| Helligkeit | 165 |
| CR | 200:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | Toshiba Matsushita |
| Panel-Modell | LTD056ET0S |
| Plattentyp | LTPS TFT-LCD , LCM |
| Panelgröße | 5.6 inch |
| Auflösung | 1024(RGB)×600 , WSVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 122.88×72 mm |
| Umriss | 141.8×84.4 mm |
| Oberfläche | |
| Helligkeit | 165 cd/m² (Typ.) |
| Kontrastverhältnis | 200:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 50 (Max.)(Tr+Td) |
| Blickwinkel | 40/40/25/30 (Typ.)(CR≥10)(L/R/U/D) |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 25 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | UMPC |
