| Artikelnummer | LS037V7DD06R |
| Marke | SHARP |
| Größe | 3.7 |
| Anwendung | MPH |
| Auflösung | 480×640 |
| Komposition | LCM |
| Helligkeit | 100 |
| CR | 100:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | TTL |
| Panel-Marke | SHARP |
| Panel-Modell | LS037V7DD06R |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 3.7 inch |
| Auflösung | 480(RGB)×640 , VGA |
| Anzeigemodus | TN, Normally White, Transflective |
| aktiver Bereich | 56.16×74.88 mm |
| Umriss | 65×90 mm |
| Oberfläche | |
| Helligkeit | 100 cd/m² (Typ.) |
| Kontrastverhältnis | 100:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 30/50 (Typ.)(Tr/Td) |
| Blickwinkel | 40/40/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDWithout Driver |
| Signalschnittstelle | Parallel RGB (1 ch, 6-bit), 51 pins |
| Eingangsspannung | 5.0/3.3/8.0/-4.0/-8.0V (Typ.)(VSHA/VSHD/VDD/VSSD/GVSS) |
| Anwendung | MPH |
