| Artikelnummer | LS013B7DH01 |
| Marke | SHARP |
| Größe | 1.26 |
| Anwendung | EPT |
| Auflösung | 144×168 |
| Komposition | LCM |
| Helligkeit | |
| CR | |
| Farben | Monochrome |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | SPI |
| Panel-Marke | SHARP |
| Panel-Modell | LS013B7DH01 |
| Plattentyp | CG-Silicon , LCM |
| Panelgröße | 1.26 inch |
| Auflösung | 144×168 |
| Anzeigemodus | Transflective |
| aktiver Bereich | 20.88×24.36 mm |
| Umriss | 24.88×33×1.75 mm |
| Oberfläche | Hard coating (3H) |
| Helligkeit | |
| Kontrastverhältnis | 20:1 (Typ.)(Reflective) |
| Farben anzeigen | Monochrome (1-bit) |
| Reaktionszeit | 10/20 (Typ.)(Tr/Td) |
| Blickwinkel | 60/60/60/60 (Typ.)(CR≥2)(L/R/U/D) |
| Lampentyp | No B/L |
| Signalschnittstelle | SPI, 14 pins |
| Eingangsspannung | 5.0/5.0V (Typ.)(VDD/VDDA) |
| Anwendung | EPT |
