| Artikelnummer | LQ156T3LW02 |
| Marke | SHARP |
| Größe | 15.6 |
| Anwendung | GM |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | |
| Farben | 16.2M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SHARP |
| Panel-Modell | LQ156T3LW02 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.6 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | ASV, Normally Black, Transmissive |
| aktiver Bereich | 344.232×193.536 mm |
| Umriss | 363.8×215.9 mm |
| Oberfläche | |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | |
| Farben anzeigen | 16.2M (6-bit + FRC), CIE193176% |
| Reaktionszeit | |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 8-bit) |
| Anwendung | GM |
