| Artikelnummer | LP156WF3-SLB3 |
| Marke | LG Display |
| Größe | 15.6 |
| Anwendung | NBPC |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 210 |
| CR | 800:1 |
| Farben | 1.07B |
| Hintergrundbeleuchtung | RGB LED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP156WF3-SLB3 2 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 15.6 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | S-IPS, Normally Black, Transmissive |
| aktiver Bereich | 344.16×193.59 mm |
| Umriss | 359.3×212.1×7.2 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 210 cd/m² (Typ.) |
| Kontrastverhältnis | 800:1 (Typ.) |
| Farben anzeigen | 1.07B (10-bit) |
| Reaktionszeit | 30 (Typ.)(Tr+Td); 15 (Typ.)(G to G) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | RGB LEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 10-bit), 50 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
