| Artikelnummer | LP140WH4-TLN1 |
| Marke | LG Display |
| Größe | 14.0 |
| Anwendung | NBPC |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 200 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | LG Display |
| Panel-Modell | LP140WH4-TLN1 30 Compatible model |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 14.0 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 309.399×173.952 mm |
| Umriss | 323.5×192×5.2 mm |
| Formstil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Oberfläche | Glare (Haze 0%), Hard coating (3H) |
| Helligkeit | 200 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit) |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 40/40/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 40 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | NBPC |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLC6 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLL1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| B133XW03 V2 | AUO | 13.3 | 1366×768 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XTT01.1 | AUO | 15.6 | 1366×768 |
| HB133WX1-402 | BOE | 13.3 | 1366×768 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP133WX2-TLD1 | LG Display | 13.3 | 1280×800 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| LTN150X5-L02 | Samsung | 15.0 | 1024×768 |
