| Artikelnummer | LK315D3LA4S |
| Marke | SHARP |
| Größe | 31.5 |
| Anwendung | LCTV |
| Auflösung | 1920×1080 |
| Komposition | LCM |
| Helligkeit | 430 |
| CR | 4500:1 |
| Farben | 1.06B |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SHARP |
| Panel-Modell | LK315D3LA4S |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 31.5 inch |
| Auflösung | 1920(RGB)×1080 , FHD |
| Anzeigemodus | ASV, Normally Black, Transmissive |
| aktiver Bereich | 698.4×392.85 mm |
| Umriss | 782×473×27.6 mm |
| Oberfläche | Antiglare (Haze 7.3%), Hard coating (2H) |
| Helligkeit | 430 cd/m² (Typ.) |
| Kontrastverhältnis | 4500:1 (Typ.) |
| Farben anzeigen | 1.06B (8-bit + FRC) |
| Reaktionszeit | 4 (Typ.)(G to G) |
| Blickwinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz (60Hz Input) |
| Lampentyp | 2 stringsWLEDWithout Driver |
| Signalschnittstelle | LVDS (2 ch, 10-bit), 55 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
