| Artikelnummer | LTA230AN01 |
| Marke | Samsung |
| Größe | 23.0 |
| Anwendung | LCTV |
| Auflösung | 1366×768 |
| Komposition | LCM |
| Helligkeit | 250 |
| CR | 4000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | SAMSUNG |
| Panel-Modell | LTA230AN01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 23.0 inch |
| Auflösung | 1366(RGB)×768 , WXGA |
| Anzeigemodus | PVA, Normally Black, Transmissive |
| aktiver Bereich | 508.152×285.696 mm |
| Umriss | 534×311.8×11 mm |
| Oberfläche | Antiglare (Haze 2.3%) |
| Helligkeit | 250 cd/m² (Typ.) |
| Kontrastverhältnis | 4000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193168% |
| Reaktionszeit | 8 (Typ.)(G to G) |
| Blickwinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 10S3PWLEDWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 8-bit), 30 pins |
| Eingangsspannung | 12.0V (Typ.) |
| Anwendung | LCTV |
