| Artikelnummer | LD070WU2-SM01 |
| Marke | LG Display |
| Größe | 7.0 |
| Anwendung | PAD |
| Auflösung | 1200×1920 |
| Komposition | LCM |
| Helligkeit | 450 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | QLED |
| Schnittstelle | MIPI |
| Panel-Marke | LG Display |
| Panel-Modell | LD070WU2-SM01 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 7.0 inch |
| Auflösung | 1200(RGB)×1920 , WUXGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 94.5×151.2 mm |
| Umriss | 104.52×161.87×2.4 mm |
| Oberfläche | Hard coating |
| Helligkeit | 450 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 16 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 4S6PQLEDWithout Driver |
| Signalschnittstelle | MIPI (4 data lanes), 40 pins |
| Eingangsspannung | 3.7/1.8V (Typ.)(VSYS/VDD) |
| Anwendung | PAD |
