| Artikelnummer | LB035Q01-TJ01 |
| Marke | LG Display |
| Größe | 3.5 |
| Anwendung | PND |
| Auflösung | 320×240 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 300:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | TTL |
| Panel-Marke | LG.Philips LCD |
| Panel-Modell | LB035Q01-TJ01 |
| Plattentyp | a-Si TFT-LCD , CELL |
| Panelgröße | 3.5 inch |
| Auflösung | 320(RGB)×240 , QVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 70.08×52.56 mm |
| Umriss | 78.1×62.95×1.53 mm |
| Oberfläche | Hard coating |
| Kontrastverhältnis | 300:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit) |
| Reaktionszeit | 30 (Typ.)(Tr+Td) |
| Blickwinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 70Hz |
| Signalschnittstelle | TTL (1 ch, 8-bit), 45 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VDD/AVDD) |
| rohs: | |
| Anwendung | PND |
| 990000738A | Innolux | 3.5 | 320×240 |
| AM-320240LATNQW-T00H-F | AMPIRE | 3.5 | 320×240 |
| LB035Q01-TJ01 | LG Display | 3.5 | 320×240 |
| LB035Q02-TD01 | LG Display | 3.5 | 320×240 |
| LB035Q03-TD02 | LG Display | 3.5 | 320×240 |
| LB035Q04-TD08 | LG Display | 3.5 | 320×240 |
| LMS350GF12-005 | Samsung | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| 35HVE0H | SII | 3.5 | 320×480 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| AT043TN13 TP | Innolux | 4.3 | 480×272 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LQ036T1DG01 | SHARP | 3.6 | 272×480 |
| LQ043T1DG04 | SHARP | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
