| Artikelnummer | KG057QV1CA-G01 |
| Marke | Kyocera |
| Größe | 5.7 |
| Anwendung | IA |
| Auflösung | 320×240 |
| Komposition | LCM |
| Helligkeit | 260 |
| CR | 4:1 |
| Farben | Monochrome |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | Kyocera |
| Panel-Modell | KG057QV1CA-G01 |
| Plattentyp | STN-LCD , LCM |
| Panelgröße | 5.7 inch |
| Auflösung | 320×240 , QVGA |
| Anzeigemodus | STN, Blue mode (Negative), Transmissive |
| aktiver Bereich | 115.18×86.38 mm |
| Umriss | 144×104.8×13.2 mm |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 260 cd/m² (Typ.) |
| Kontrastverhältnis | 4:1 (Typ.) |
| Farben anzeigen | Monochrome |
| Reaktionszeit | 210/130 (Typ.)(Tr/Td) |
| Blickwinkel | 45/45/20/45 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 75Hz |
| Lampentyp | 1 pcsCCFLOptional |
| Signalschnittstelle | Parallel Data (4-bit), 20 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VDD) |
| Anwendung | IA |
