| Artikelnummer | TX31D200VM0BAA |
| Marke | KOE |
| Größe | 12.3 |
| Anwendung | IA |
| Auflösung | 1280×480 |
| Komposition | LCM |
| Helligkeit | 1000 |
| CR | 1000:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | KOE |
| Panel-Modell | TX31D200VM0BAA |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.3 inch |
| Auflösung | 1280(RGB)×480 , DVGA |
| Anzeigemodus | IPS, Normally Black, Transmissive |
| aktiver Bereich | 291.84×109.44 mm |
| Umriss | 320×130×12.6 mm |
| Oberfläche | Antiglare |
| Helligkeit | 1000 cd/m² (Typ.) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193170% |
| Reaktionszeit | 25 (Typ.)(Tr+Td) |
| Blickwinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | WLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AC150XA02 | Mitsubishi | 15.0 | 1024×768 |
| EL640.400-CB1 FRA | Lumineq | 9.1 | 640×400 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| NL8060BC31-41E | NLT | 12.1 | 800×600 |
