| Artikelnummer | KCG089HV1AA-G00 |
| Marke | Kyocera |
| Größe | 8.9 |
| Anwendung | IA |
| Auflösung | 640×240 |
| Komposition | LCM |
| Helligkeit | 150 |
| CR | 30:1 |
| Farben | Color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Parallel Data |
| Panel-Marke | Kyocera |
| Panel-Modell | KCG089HV1AA-G00 |
| Plattentyp | CSTN-LCD , LCM |
| Panelgröße | 8.9 inch |
| Auflösung | 640(RGB)×240 , HVGA |
| Anzeigemodus | STN, Normally Black, Transmissive |
| aktiver Bereich | 211.18×79.18 mm |
| Umriss | 246×103×12.2 mm |
| Oberfläche | Glare (Haze 0%) |
| Helligkeit | 150 cd/m² (Typ.) |
| Kontrastverhältnis | 30:1 (Typ.) |
| Farben anzeigen | Color |
| Reaktionszeit | 190/180 (Typ.)(Tr/Td) |
| Blickwinkel | 50/50/35/20 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 75Hz |
| Lampentyp | 1 pcsCCFLOptional |
| Signalschnittstelle | Parallel Data (8-bit), 20 pins |
| Eingangsspannung | 3.3/5.0V (Typ.)(VDD) |
| Anwendung | IA |
