| Artikelnummer | HV121P01-100 |
| Marke | HYDIS |
| Größe | 12.1 |
| Anwendung | PAD |
| Auflösung | 1400×1050 |
| Komposition | LCM |
| Helligkeit | 190 |
| CR | 500:1 |
| Farben | 262K |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | BOE HYDIS |
| Panel-Modell | HV121P01-100 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 1400(RGB)×1050 , SXGA+ |
| Anzeigemodus | AFFS, Normally Black, Transmissive |
| aktiver Bereich | 245.7×184.275 mm |
| Umriss | 270×199×7 mm |
| Oberfläche | Antiglare (Haze 40%), Hard coating (2H) |
| Helligkeit | 190 cd/m² (Typ.) |
| Kontrastverhältnis | 500:1 (Typ.) |
| Farben anzeigen | 262K (6-bit), CIE193143% |
| Reaktionszeit | 20/20 (Typ.)(Tr/Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | PAD |
| B121EW03 V7 | AUO | 12.1 | 1280×800 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HV121P01-100 | HYDIS | 12.1 | 1400×1050 |
| HV121P01-101 | HYDIS | 12.1 | 1400×1050 |
| LM12S389 | SHARP | 12.1 | 800×600 |
| LTD121EW3D | TOSHIBA | 12.1 | 1280×800 |
| LTN121AT11-801 | Samsung | 12.1 | 1280×800 |
| MAA121DSK26 | Mitsubishi | 12.1 | 800×600 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| CLAP070WP03XG | CPT | 7.0 | 800×1280 |
| HV101HD1-1E2 | HYDIS | 10.1 | 1366×768 |
| LP079X01-SMA1 | LG Display | 7.9 | 768×1024 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
