| Artikelnummer | H572DAN01.2 |
| Marke | AUO |
| Größe | 5.7 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | MIPI |
| Panel-Marke | AUO |
| Panel-Modell | H572DAN01.2 |
| Plattentyp | LTPS TFT-LCD , CELL |
| Panelgröße | 5.7 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 71.28×126.72 mm |
| Umriss | 73.68×133.27 mm |
| Oberfläche | Hard coating |
| Glastiefe | 0.15+0.15 mm |
| Durchlässigkeit | 4.8% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193172% |
| Reaktionszeit | 20/15 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Treiber-IC | COG Built-in R63311 |
| Anwendung | MPH |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| EL320.240.36 HB NE | PLANAR | 5.7 | 320×240 |
| G057VN01 V1 | AUO | 5.7 | 640×480 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| KCS057QV1AJ-G20 | Kyocera | 5.7 | 320×240 |
| LM057QB1T073 | SHARP | 5.7 | 320×240 |
| LM057QB1T09 | SHARP | 5.7 | 320×240 |
| LM057QC1T01 | SHARP | 5.7 | 320×240 |
| T78AAVGTF0 | Other | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
| BTL507212-W677L | BOE | 5.0 | 720×1280 |
| CLAF055WB41 TXX | CPT | 5.5 | 720×1280 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| CT035TN02 | Innolux | 3.5 | 320×480 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LS035Y8DX02A | SHARP | 3.5 | 480×800 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LT044MDW7000 | TOSHIBA | 4.5 | 720×1280 |
