| Artikelnummer | H497DAN01.0 |
| Marke | AUO |
| Größe | 5.0 |
| Anwendung | MPH |
| Auflösung | 1080×1920 |
| Komposition | CELL |
| Helligkeit | 0 |
| CR | 1000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | No B/L |
| Schnittstelle | |
| Panel-Marke | AUO |
| Panel-Modell | H497DAN01.0 |
| Plattentyp | LTPS TFT-LCD , CELL |
| Panelgröße | 5.0 inch |
| Auflösung | 1080(RGB)×1920 , FHD |
| Anzeigemodus | AHVA, Normally Black, Transmissive |
| aktiver Bereich | 61.884×110.016 mm |
| Umriss | 63.89×117.47×0.576 mm |
| Oberfläche | Hard coating |
| Glastiefe | 0.15+0.15 mm |
| Durchlässigkeit | 3.72% (Typ.)(with Polarizer) |
| Kontrastverhältnis | 1000:1 (Typ.) |
| Farben anzeigen | 16.7M (8-bit), CIE193170% |
| Reaktionszeit | 20/15 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Treiber-IC | COG Built-in NT35596 |
| Anwendung | MPH |
