| Artikelnummer | G190SVT01.0 |
| Marke | AUO |
| Größe | 19.0 |
| Anwendung | IA |
| Auflösung | 1680×342 |
| Komposition | LCM |
| Helligkeit | 260 |
| CR | 2000:1 |
| Farben | 16.7M |
| Hintergrundbeleuchtung | WLED |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | G190SVT01.0 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 19.0 inch(1/3 cut of 22.0") |
| Auflösung | 1680(RGB)×342 |
| Anzeigemodus | MVA, Normally Black, Transmissive |
| aktiver Bereich | 473.76×96.44 mm |
| Umriss | 497.7×126.8×21.66 mm |
| Oberfläche | Antiglare, Hard coating (7H) |
| Helligkeit | 260 cd/m² (Typ.) |
| Kontrastverhältnis | 2000:1 (Typ.) |
| Farben anzeigen | 16.7M (6-bit + Hi-FRC), CIE193168% |
| Reaktionszeit | 8 (Typ.)(G to G); 20 (Typ.)(Tr+Td) |
| Blickwinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 8S5PWLEDEmbedded (LED Driver) |
| Signalschnittstelle | LVDS (2 ch, 8-bit), 30 pins |
| Eingangsspannung | 5.0V (Typ.) |
| Anwendung | IA |
