| Artikelnummer | G121SN01 V3 |
| Marke | AUO |
| Größe | 12.1 |
| Anwendung | IA |
| Auflösung | 800×600 |
| Komposition | LCM |
| Helligkeit | 400 |
| CR | 600:1 |
| Farben | 262K/16.2M |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | LVDS |
| Panel-Marke | AUO |
| Panel-Modell | G121SN01 V3 |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 12.1 inch |
| Auflösung | 800(RGB)×600 , SVGA |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 246×184.5 mm |
| Umriss | 279×209×11 mm |
| Oberfläche | Antiglare, Hard coating (3H) |
| Helligkeit | 400 cd/m² (Typ.) |
| Kontrastverhältnis | 600:1 (Typ.) |
| Farben anzeigen | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| Reaktionszeit | 10/25 (Typ.)(Tr/Td) |
| Blickwinkel | 80/80/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 2 pcsCCFLWithout Driver |
| Signalschnittstelle | LVDS (1 ch, 6/8-bit), 20 pins |
| Eingangsspannung | 3.3V (Typ.) |
| Anwendung | IA |
| G121S1-L01 | Innolux | 12.1 | 800×600 |
| G121S1-L02 | Innolux | 12.1 | 800×600 |
| G121SN01 V0 | AUO | 12.1 | 800×600 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| G121SN01 V3 | AUO | 12.1 | 800×600 |
| G121SN01 V4 | AUO | 12.1 | 800×600 |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| LQ121S1DG61 | SHARP | 12.1 | 800×600 |
| LTD121ECBP | TOSHIBA | 12.1 | 1024×768 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| FX050700DSCWDG12 | Data Image | 5.7 | |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM5Q321 | SHARP | 5.0 | 320×240 |
| NL6448BC20-35D | NLT | 6.5 | 640×480 |
| TFD60W12-B | TOSHIBA | 6.0 | 320×234 |
| TM057KDH01 | Tianma | 5.7 | 320×240 |
| TX26D17VM2BAA | KOE | 10.4 | 640×480 |
