| Artikelnummer | TFD60W12-B |
| Marke | TOSHIBA |
| Größe | 6.0 |
| Anwendung | IA |
| Auflösung | 320×234 |
| Komposition | LCM |
| Helligkeit | 280 |
| CR | 80:1 |
| Farben | Full color |
| Hintergrundbeleuchtung | CCFL |
| Schnittstelle | Analog |
| Panel-Marke | TOSHIBA |
| Panel-Modell | TFD60W12-B |
| Plattentyp | a-Si TFT-LCD , LCM |
| Panelgröße | 6.0 inch |
| Auflösung | 320(RGB)×234 |
| Anzeigemodus | TN, Normally White, Transmissive |
| aktiver Bereich | 121.92×89.154 mm |
| Umriss | 144×109.4 mm |
| Oberfläche | Antiglare, Antireflection |
| Helligkeit | 280 cd/m² (Typ.) |
| Kontrastverhältnis | 80:1 (Typ.) |
| Farben anzeigen | Full color |
| Reaktionszeit | 70/40 (Max.)(Tr/Td) |
| Blickwinkel | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampentyp | 1 pcsCCFLWithout Driver |
| Signalschnittstelle | TFT Specific Analog RGB, 24 pins |
| Eingangsspannung | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
| Anwendung | IA |
